For many users, Intel Dual Band Wireless 8260 AC has been a issue of distress because of highly cynical speed of Wireless and this has affected the networking via wireless difficult and highly variable speed in internet surfing. Overall you’ll face fluctuations in internet and would observe a disastrous difference between you really used to have in Windows 7 or 8. And it’s not like that things have been any better with 8260 AC card with Windows 8, but however it was manageable. Now, you’ll have great trouble in playing online games like Counter Strike where lower the ping the best situation is a must. So, let’s fix this issue:

Solution 1

Intel Dual Band Wireless 8260 AC card designed for work mainly for 5GHz AC connections. But since most users using laptop of many manufacturer say HP, Lenovo or even Dell have this card in their laptop. Intel shouldn’t have sold this card in bulk as in the end it’s the consumer who suffer. However to fix this issue, let’s begin:

Download latest drivers from Intel here. You’ll get two choices to choose from i.e.

For Windows 8 / 10 32 Bit	For Windows 8 / 10 64 bit
Wireless Driver Only – Version 18.12.0	Wireless_18.12.0_De132.exe	Wireless_18.12.0_De164.exe
Intel PROSet/Wireless WiFi Software (includes Drivers) – Version 18.12.0	Wireless_18.12.0_t32.exe	Wireless_18.12.0_t64.exe

This driver is applicable for following Intel adapters:

2 4	Intel® Dual Band Wireless–AC7260 Intel® Dual Band Wireless–N7260

I do not care the AC support. I do care to have N and below support with AP mode since I am planning to use the pfsense as a Wireless Router. The hardware only have limited Wireless Cards options. Intel AC-3165, AC-7265, AC-8260. The Lenovo Y700 comes with a new wireless card inside, which is the Intel Dual Band Wireless-AC 8260. This upgraded adapter utilizes the M.2 form factor and is the latest iteration of Intel’s lineup of wireless adapters. Intel cards have tended to be reliable, but not the fastest card out there, at least on the models that we’ve tested. OS X Updates The Workshop. Intel (R) Dual Band Wireless-AC 8260 problem. But i have tryed many way to get wifi to work just failed. Intel daul band wireless. Support product highlights, featured content, downloads and more for Intel® Dual Band Wireless-AC 8260. Intel Core i5-6200U Processor Base, Integrated HD Graphics 520. Internal Italian Qwerty Backlit Dual Pointing Keyboard. Intel Dual-Band Wireless-AC 8260;Wi-Fi + BT 4.2 Wireless Card. M.2 256GB SATA Class 20 Solid State Drive HYNIX SC308. 12GB DDR4 2133MHz Memory. 35.6cm (14.0 ') HD (1366x768) Non-Touch Anti-Glare LCD with Camera and Mic.

PROSet version = 18.12.0

Driver version = 18.12.0.3 for Windows 10 for 7265, 7260, 3165, and 3160 adapters.
Driver version = 15.18.0.1 for Windows 10 for 105, 135, 2230, 6205, 6235, and 6300 adapters.
How to install a52codec.component. Driver version = 15.12.0.9 for Windows 10 for 2200, 6150, and 6250 adapters.

1. Install the Intel Wireless Driver. If you had Intel PROset previously in laptop, install that one, otherwise install the driver version only.
2. Now many of users might face internet connectivity issue and shall see “Limited Connection” or the Internet might be very slow to load new pages. This happens because it’s not the manufacturer version driver, hence it needs to be configured properly for using it on older hardware. These solutions provided below are valid for Windows 7, 8 and 10 for all the wireless adapters i listed above.
3. Right click on Wireless icon and select “Open Network and Sharing Center“.
4. Click “Change Adapter Settings“.
5. Right click on wireless connection and select Properties.
6. Click “Configure“.
7. When Network Adapter Properties open, select “Advanced” tab and change the settings as given below:

   2 4	–802.11nchannel Width for2.4Ghzconenctions to20mhzONLY(Defualt isAuto) –Roaming Agressiveness1.Lowest(Defualt is3.Medium) –Set HT mode toVHT mdoe

8. Login into your router settings and disable P2P settings and Enable WMM (Wi-Fi multimedia)

Intel Dual Band Wireless Ac 8260 Problems

1. If you play Xbox or have the app installed, open and sign in and then go to settings and disable “Game DVR“.
2. Open Wireless Settings and disable auto connecting to wireless hotspots.
3. Also, last if you’re not using any bluetooth device, switch OFF bluetooth too in Windows 10 settings.

Solution 2

Another issue for fluctuating speed could happen because of Power Save Polling (PSP) issues with Access points. According to Intel, if a WiFi router doesn’t support Power save Polling (PSP) feature, than it can create issues like, Intermittent loss of loss of Wi-Fi connection, Inability to initiate a Wi-Fi connection, Poor Wi-Fi connection data performance. These issues are most noticeable when the computer is on battery power.

PSP mode is a feature built to increase battery life of laptops and notebooks. However this mode requires a coordination between the Access point and the Wi-Fi router. But later on it was discovered by Intel that some access points or routers are not able to support PSP correctly or doesn’t support at all.

The only solution to check or ask manufacturer if there is any updated firmware of the router. If there is no such update, then there is one turn-around to set the wi-fi adapter of your computer to Continuously Aware Mode (CAM). Enabling this would disable the PSP feature. You can enable the CAM feature by following given methods:

• Intel PROSet/Wireless WiFi Connection Utility
• Network control panel applet (NCPA)

Intel Dual Band Wireless Ac 8260 Manual

Be cautious, as this feature in some models can hinder Bluetooth functionality.

How to Enable Continuously Aware Mode using Intel PROSet/Wireless WiFi Connection Utility

From the Intel PROSet/Wireless WiFi Connection Utility:

1. Click Advanced > Adapter Settings > Advanced tab.
2. Windows XP*: Select Power Management, uncheck Default / Auto, and move the slider to Highest / Maximum Performance.
3. Windows 7 or 8 or 10: Select Transmit Power, change Value to 5. Highest.

How to Enable Continuously Aware Mode using Network Control Panel Applet (NCPA)

1. Click Start > Settings > Control Panel.
2. Double-click Network Connections.
3. Right-click the wireless connection and click Properties.
4. Click Configure.
5. Click the Advanced tab.
6. Windows XP: Select the Power Management setting, uncheck Default / Auto, and move the slider to Highest / Maximum Performance.
7. Windows 7 or 8: Select Transmit Power, change Value to 5. Highest.

Above method fixes WiFi issues of following Intel Wireless adapter models:

Intel Ac 8260 Wireless Card

2 4 6 8 10 12 14 16 18 20 22 24 26 28

Intel Centrino Advanced–N6200 Intel Centrino Advanced–N6205ForDesktop Intel Centrino Advanced–N6235 Intel Centrino Wireless–N+WiMAX6150 Intel Centrino Wireless–N1000 Intel Centrino Wireless–N130 Intel Centrino Wireless–N2200ForDesktop Intel Dual Band Wireless–AC3160 Intel Dual Band Wireless–AC7260forDesktop Intel PRO/Wireless2200BGNetwork Connection Intel PRO/Wireless3945ABGNetwork Connection Intel WiFi Link1000 Intel WiMAX/WiFi Link5350andIntel WiMAX/WiFi Link5150products Intel Wireless–N7260
